Product features:
2V025 Series
1. Direct acting normally closed two position two port solenoid valve, quick and sensitive reversing;
2. Compact structure;
3. The valve body material is available in aluminum alloy or brass, the electromagnetic coil has a heat resistance grade of B, and the sealing material is fluororubber, which can be suitable for various working media.
2V130/2V250 Series
1. Diaphragm pilot type two position two port solenoid valve, low energy consumption, high flow rate;
2. Low opening pressure, minimum operating pressure difference of 0.05MPa;
3. The valve body material is brass, the electromagnetic coil heat resistance grade is B, and the sealing material is NBR.
